OVERVIEW
Keep an Eye on Your Environment from Miles Away
The HOBOnet Wireless Temperature Sensor provides a cost-effective and scalable solution for web-enabled monitoring of air temperature. HOBOnet wireless sensors communicate data directly to a HOBO RX Station or pass data through other wireless sensors back to the central station. They are preconfigured and ready to deploy, and data is accessed through HOBOlink, Onset’s innovative cloud-based software platform.
Features
Sensor Features
- Measurement range of -40° to 100°C (-40° to 212°F)
- High accuracy: ± 0.2°C ( ± 0.36°F)
- Stainless-steel sensor tip
Wireless Features- 900 MHz wireless mesh self-healing technology
- 450 to 600 meter (1,500 to 2,000 feet) wireless range and up to five hops
- Up to 50 wireless sensors or 336 data channels per HOBO RX station
- Simple button-push to join the HOBOnet wireless network
- Onboard memory to ensure no data loss
- Powered by rechargeable AA batteries and built-in solar panel
Important Information
Includes lithium batteries. A complete system requires a HOBO RX Station, a HOBOnet Wireless Manager, and a HOBOnet Wireless Sensor. HOBOnet Wireless Repeaters can be added to extend the range of both system options.
-
SPECIFICATIONS
Sensor
Measurement Range -40° to 100°C (-40° to 212°F) Accuracy ±0.25°C from -40° to 0°C (±0.45°F from -40° to 32°F)
±0.20°C from 0° to 70°C (±0.36°F from 32° to 158°F)
±0.25°C from 70° to 100°C (±0.45°F from 158° to 212°F)Resolution 0.02°C (0.036°F) Drift <0.01°C (0.018°F) per year Response Time (typical, to 90% of change) 2 minutes, 30 seconds in air moving 1 m/sec Wireless Mote
Operating Temperature Range -40° to 70°C (-40° to 158°F) Radio Power 12.6 mW (+11 dBm) non-adjustable Transmission Range Reliable connection to 457.2 m (1,500 ft) line of sight at 1.8 m (6 ft) high
Reliable connection to 609.6 m (2,000 ft) line of sight at 3 m (10 ft) highWireless Data Standard IEEE 802.15.4 Radio Operating Frequencies RXW-TMB-x-900: 904–924 MHz
RXW-TMB-x-868: 866.5 MHz
RXW-TMB-x-921: 921 MHz
RXW-TMB-x-922: 916–924 MHzModulation Employed OQPSK (Offset Quadrature Phase Shift Keying) Data Rate Up to 250 kbps, non-adjustable Duty Cycle <1% Maximum Number of Motes Up to 50 wireless sensors or 336 data channels per one HOBO RX station Logging Rate 1 minute to 18 hours Number of Data Channels 2 Battery Type Two AA 1.5 V lithium batteries Battery Life 1 year, typical use Memory 16 MB Dimensions Sensor: 5.1 x 33 mm (0.2 x 1.3 inches)
Cable length: 0.3 m (1 ft), RXW-TMB-1-xxx; 1.8 m (6 ft), RXW-TMB-6-xxx
Mote: 16.2 x 8.59 x 4.14 cm (6.38 x 3.38 x 1.63 inches)Weight Sensor and cable: 7.6 g (0.27 oz), RXW-TMB-1-xxx; 35.2 g (1.24 oz), RXW-TMB-6-xxx
Mote: 223 g (7.87 oz)Materials Sensor: Stainless steel waterproof tip
Mote: PCPBT, silicone rubber sealEnvironmental Rating Sensor and cable: Immersion in water up to 50°C (122°F) for 1 year
Mote: IP67, NEMA 6Compliance Marks See User Manual
HOBOnet Wireless Temperature Sensor (Battery Powered)
$418.00 – $441.00 ex GST
The HOBOnet Wireless Temperature Sensor provides a cost-effective and scalable solution for web-enabled monitoring of air temperature.
