OVERVIEW
Get Accurate Measurement Results Instantly
The HOBOnet Wireless Temperature and Relative Humidity Sensor provides a cost-effective and scalable solution for web-enabled monitoring of air temperature and humidity. HOBOnet Wireless Sensors communicate data directly to the RX Station or pass data through other wireless sensors back to the central station. They are preconfigured and ready to deploy, and data is accessed through HOBOlink, Onset’s innovative cloud-based software platform.
Features
Sensor Featuures
- High accuracy: ± 0.2°C (± 0.36°F) and ± 2.5% RH
- Robust RH sensor withstands extended use in high-humidity environments
Wireless Features
- 900 MHz wireless mesh self-healing technology
- 450 to 600 meter (1,500 to 2,000 feet) wireless range and up to five hops
- Up to 50 wireless sensors per RX Station
- Simple button-push to join the HOBOnet wireless network
- Onboard memory to ensure no data loss
- Powered by 2 user-replaceable lithium AA batteries
Impotant Information
Includes lithium batteries. A complete system requires a HOBO MicroRX Station, which has an integrated HOBOnet Wireless Manager, and a HOBOnet Wireless Sensor. HOBOnet Wireless Repeater (RXW-RPTR-B-xxx) can be added to extend the range of both system options.
-
SPECIFICATIONS
Sensor
Temperature RH Measurement Range -40°C to 75°C (-40°F to 167°F) 0–100% RH at -40° to 75°C (-40° to
167°F); exposure to conditions
below -20°C (-4°F) or above 95%
RH may temporarily increase the
maximum RH sensor error by an
additional 1%Accuraqcy ±0.25°C from -40° to 0°C (±0.45°F
from -40° to 32°F)
±0.20°C from 0° to 70°C (±0.36°F
from 32° to 158°F)
±0.25°C from 70° to 75°C (±0.45°F
from 158° to 167°F)±2.5% from 10% to 90% RH
typical to a maximum of ±3.5%
including hysteresis at 25°C
(77°F); below 10% and above
90% ±5% typicalResolution 0.02°C (0.036°F) 0.01% RH Drift <0.01°C (0.018°F) per year <1% per year typical Response Time (typical, to
90% of change)3 minutes, 45 seconds in air
moving 1 m/s15 seconds in air moving 1 m/s Wireless Mote
Operating Temperature
Range-40° to 70°C (-40° to 158°F) Radio Power 12.6 mW (+11 dBm) non-adjustable Transmission Range Reliable connection to 457.2 m (1,500 ft) line of sight at 1.8 m (6 ft) high
Reliable connection to 609.6 m (2,000 ft) line of sight at 3 m (10 ft) highWireless Data Standard IEEE 802.15.4 Radio Operating
FrequenciesRXW-THC-B-900: 904–924 MHz
RXW-THC-B-868: 866.5 MHz
RXW-THC-B-921: 921 MHz
RXW-THC-B-922: 916–924 MHzModulation Employed OQPSK (Offset Quadrature Phase Shift Keying) Data Rate Up to 250 kbps, non-adjustable Duty Cycle <1% Maximum Number of
MotesUp to 50 wireless sensors or 336 data channels per one HOBO RX station Logging Rate 1 minute to 18 hours Number of Data Channels 3 Battery Type Two AA 1.5 V lithium batteries Battery Life 1 year, typical use Memory 16 MB Dimensions Sensor: 45.97 x 11.43 x 10.16 mm (1.81 x 0.45 x 0.40 inches)
Mote: 16.2 x 8.59 x 4.14 cm (6.38 x 3.38 x 1.63 inches)Weight 223 g (7.87 oz) Materials Sensor: Polyamide
Mote: PCPBT, silicone rubber sealEnvironmental Rating IP67, NEMA 6 Compliance Marks See User Manual
HOBOnet Wireless Temp/RH Sensor (Battery Powered)
$557.00 ex GST
The HOBOnet Wireless Temperature and Relative Humidity Sensor provides a cost-effective and scalable solution for web-enabled monitoring of air temperature and humidity. HOBOnet Wireless Sensors communicate data directly to the RX Station or pass data through other wireless sensors back to the central station.
