• Programmable via USB (requires the XU-USB programming key).
• No power supply or calibration required during programming.
• Input Types:
  • RTD Pt100 and Pt1000.
  • Thermocouple B, E, J, K, N, R, S, T.
  • For RTD and Thermocouple; Output is Linear with Temperature.
  • mA, mV and V.
  • Potentiometer.
  • 32 point curve fitter for mA, mV, V inputs.
• Input to Output Isolation 3750Vac.
• High Accuracy 0.1%.
• Universal AC/DC Power Supply; 20~265Vac or 21~100Vdc.
• Reverse Polarity Protection.
• Heartbeat Status LED.
• Case Temperature range -20°C to +80°C.
• Compact DIN Rail Mount Enclosure.
• Easy to Install.
• Low Cost.

Note: Requires the XU-USB programming key, or OneTemp can calibrate to your requirements before dispatch.

Click here to Download FREE Programming Software



• Output 4 wire
  • Voltage Field Programmable from 0V~10V, 10V~0V, +10V to (-10V), -10V to +10V Maximum Output Drive = 10.4Vdc. (520Ω@20mA.)
  • Current Field Programmable from 4~20mA, 0~20mA, 20~4mA & 20~0mA Maximum Output Drive = 20mA (650Ω maximum load @13Vdc.)
• Universal P/S: 20~265Vac and 21~265Vdc
  • Circuit Sensitivity <±0.001%/V FSO Typical.
• EMC Emissions Compliance EN 61326
• EMC Immunity Compliance EN 61326
• Safety Compliance EN 61010-1
• Accurate to <±0.03% FSO Typical.
• Linearity & Repeatability <±0.02% FSO Typical. (Unless Individual Specifications State Otherwise.)
• Ambient Drift <±0.003%/C FSO Typical.
• Noise Immunity 125dB CMRR Average. (2.0kVdc Limit.)
• R.F Immunity <1% Effect FSO Typical.
• Signal Isolation Voltage Between Input and Output 3750Vac for 1 min.
• Response Time 400msec Typical. (From 10 to 90% 300msec Typical)
• Output calibrate via Pot ±0.5mA Zero offset adjust
• Error Detection LED indication for sensor errors.
• Operating Temperature -20~85°C.
• Storage Temperature -20~100°C.
• Operating Humidity 5~85%RH Max. Non-Condensing.
• Mounting 35mm Symmetrical Mounting Rail.
• Dimensions H=79, W=30, D=68mm.
