• Standard round pin socket rated to 220°C
• Available in all thermocouple types
• IEC 60584.3 or ANSI MC96.1 colour codes (DIN and JIS colours are also available)
• Accepts stranded or solid wires from 0.2mm to 1.29mm diameter (0.03mm² to 1.3mm²). Or up to 1.63mm diameter (2.1mm²) with washer removed
• High purity thermocouple alloys used for male pins and female socket connections
• Polarised round pins
• Choice of solid or hollow pins
• Easy wiring via lipped washer
• Single captive screw for quick assembly
• Manufactured in accordance with standard EN 50212

Cable Clamp

The Cable clamp allows the user to clamp wires and cables in place. It is constructed from stainless steel including stainless steel screws and is temperature rated to 1470°F (only limited by the temperature rating of the cable or connector it is attached to).

Cable Grommet

The cable grommet is fitted into the exit hole of the connector which prevents dirt or moisture entering the connector when used with wires or cable.
It is constructed with a silicone rubber ring with collar, slit for easy use. Compresses on the wire or cable when connector is fully assembled. It is rated to 390°F.

Cable Bending Protection

Provides bending protection for small wires and cables when used with miniature connectors. Reduces potential mechanical damage to the cable. The conical end can be cut back to suit the cable. It is constructed from silicone rubber and is rated to temperatures up to 390°F.
